1. If you are installing our boot on an AODE-equipped car: turn the car on to the pre-ignition stage (one click before
starting the car.) Depress the brake pedal and move your shifter to first (low)
gear. To remove the shift knob, use a 5/64 allen wrench and unscrew the screw
that faces the dash. Make sure you unscrew it fully.
If your car is a manual, remove the shift knob by unscrewing it. Use
vice-grips after wrapping the knob with a towel to protect it from scratching.
Make sure you hold the shift lever underneath the shift knob with another wrench
to protect it from turning, which may be harmful for the transmission. You want
to twist off just the shift knob, not the whole shift lever. :)
|
 |
|
2. Pull up on the knob until it comes loose. This will take some
force but be careful not to break the wires that are connected to the overdrive.
Once the knob if off you will need to cut the overdrive wires somewhere in the
middle so you will be able to splice them back together later.
Use a screwdriver
wrapped in a cloth and gently pry off the shifter bezel beginning at the top.
|
 |
|
3. Once the bezel is loose disconnect the cigarette lighter and place
the bezel aside. Remove the existing boot by unscrewing the 6 nuts that hold it
on. Install the new boot in it's place.
You need to use a zip-tie make sure the top of the boot holds up against the
shift lever. Flip the boot inside-out, slide it top-first onto the shifter and
secure with a zip-tie. Then pull the boot down over the shifter. Doing that on
an AUTO, make sure the OD wires are routed through the boot properly.
Unless you are installing the ebrake boot, you are almost done - proceed to
step #7.
|
 |
|
4. To install the ebrake boot, first remove the two screws near the radio bezel that holds the center
console on. Remove the two screws inside the center console compartment that
hold the compartment to the console. They are covered with rubber limiters that
the armrest lid rests on.
|
 |
|
5. Remove the screws that attach the console to the floor visible
after you removed the center console compartment lining (this should completely unattach the console from
the floor).
|
 |
|
6. Pull the e-brake up as far as possible, work the existing boot
over the e-brake and remove the center console.
If you car is a 94-00, it did not come with a vinyl factory boot, all it has
is a rubber dust guard. Remove the dust guard and install the boot instead of it.
You can use the dust guard to hold the boot to the center console or remove it
altogether. As for installing the e-brake boot, you might want to glue it to the
center console. Use any epoxy-based glue (Automotive GOOP or a similar product) and take your time.
|
 |
|
7. Reinstall the shifter bezel
and shift knob at
the very end.
|
|
|
ENJOY YOUR NEW LEATHER BOOTS!
|
|
Useful tip
You have installed a product made out of genuine leather. As you know, to maintain a leather product in good condition, you should take care of it. We suggest occasionally (every 4-6 week for example) applying some leather conditioner/UV protector to keep your leather from drying up in the sun and cracking.
